Constmach JS-1 - Mobile Crusher Plant in İzmir, Turkey
New
Doubleclick to zoom in
Contact the seller for
additional photos and information.
Specifications
- Condition
- new
- Production capacity
- 60-80 tph
- Maximum feeding size
- 600 x 380 mm
- Feeding height
- 4.5 meters
- Main configuration
- Primary Jaw + Secondary Impact + Vibrating Screen
- Total motor power
- 275 kW
- Electric generator requirement
- 550 kVA
- Weight of the plant
- 60.000 kg
- Sizes of the plant
- 1st chassis: 11(L) x 3(W) x 4.4(H) meters 2nd chassis: 17.8(L) x 4.3(W) x 3.35(H) meters
- Chassis type
- Double chassis
- Subcategory
- Mobile crushing plants
- Subcategory 2
- Mobile jaw and impact crushers
- Listing ID
- 91520111
Description
CONSTMACH JS-1 Mobile Crushing and Screening plant is used for processing of materials with middle hardness grade such as limestone, riverstone, dolomite etc.
JS-1 is the result of sophisticated engineering and advanced design, high quality components with long-lasting and excellent craftsmanship.
JS-1 Mobile Crushing Plant is combination of:
1st Chassis:
Feeding Hopper with Vibrating Feeder
CJC-60 Primary Jaw Crusher
By-pass Conveyor (for extraction of soil
Feeding Conveyor
Wheeled Mobile Chassis with Hydraulic Legs
Power & Control Panel
2nd Chassis:
CSI 1210 Secondary Impact Crusher
Vibrating Screen with 3 Decks
Feedback Conveyor from Vibrating Screen to the Hopper of Secondary Impact Crusher
Fold-up Type Stockpile Conveyors
Wheeled Mobile Chassis with Hydraulic Legs
Power & Control Panel
Dust Removing System
Diesel Electric Generator Set (Optional Application)
JS-1 Production capacity changes between 60 to 80 tonnes per hour according to hardness level of stones to be crushed.
