8 Ton Empty Container Handler 6 in Beijing, China
New
Doubleclick to zoom in
Contact the seller for
additional photos and information.
Specifications
- Condition
- new
- Power unit
- Diesel
- Operation type
- Driver seated
- Load capacity
- (kg); 8000
- Max. stacking layer
- ; 6
- Lift speed, laden/unladen
- m/s; 0.55/0.60
- Lowering speed, laden/unladen
- m/s; 0.60/0.60
- Travel speed, laden/unladen
- Km/h; 25/27
- Climbing ability, laden
- %; 30
- Tractive force
- kN; 107.5
- Wheel base
- y (mm); 4020
- Height of mast, lowered
- h1 (mm); 9600
- Tilt angle, forward/backward
- α/β（/°）; 3/4
- Height of mast, extended
- h4 (mm); 16660
- Height of cabin
- h6 (mm); 4326
- Height, operator's seat
- h7 (mm); 3206
- Twist lock height, lowered
- h13 (mm); 2290
- Max. twistlock height
- h3 (mm); 16290
- Overall length
- l1 (mm); 6450
- Length to spreader face
- l2 (mm); 6277
- Overall width
- b1/b2 (mm); 3627/2398
- Width of spreader 20'/40'
- b3 (mm); 6050/12150
- Turning radius
- Wa (mm); 5700
- Wheelspan, front wheels
- b10 (mm); 2880
- Wheelspan, rear wheel
- b11 (mm); 2068
- Service weight
- kg; 32800
- Axle load with load, front/rear
- kg; 28650/10150
- Axle load without load, front/rear
- kg; 19700/13100
- Brand
- ; Kessler/Germany
- Cylinder no./displacement
- ; 6/6700 cm3
- Rated power @ rated speed
- ; 129kw @ 2200rpm
- Max. torque
- ; 800Nm@ 1500rpm
- Rated current of alternator
- ; 70A
- Battery
- ; 24V (2x12/110)
- Transmission
- ; Auto-shift/interlock
- Clutch type
- ; Torque converter
- Gear no.
- ; 3F/3R
- Service brake
- ; wet-disc
- Parking brake
- ; Brake enabled when power off
- Steering type-single cylinder
- ; Double action cylinder
- Drive wheels
- ; 12.00-24 24PR
- Steering wheels
- ; 12.00-24 24PR
- Pressure
- ; 10 bar
- Quantity, front/rear
- ; 4/2
- Subcategory
- Port machinery
- Listing ID
- 87727360
Description
6 layer empty container handler,8 layer empty container handler
VICGORDAN Empty Container Handler Suppliers Empty Container Handler advantages:
Technical Specifications Engine :--Cummins QSB6.7-C220, 164kw@2300rpmTransmission:--German ZF 3WG211, 3/3 gears auto-shiftDrive axle/:--German Kessler D81PL488-NLB wide typeSteer axle:--Italy OMCIT
8 tons 8t empty container handler side loader ECH Brand VICGORDAN vs Fantuzzi, Kalmar, Hyster, Sany, Konecranes, CVS
Kessler D81 Drive Axle
Kessler drive axle, proven quality for heavy duty trucks, wide track, 2-stages reduction gear box, strong axle body optimized for heavy loading condition. Wet disk driving brake is free of maintenance.
This drive axle performs under shock load condition ensuring high safety and long life time.
Equipped with cummins engine, with full electrical control system to ensure economic fuel consumption
Equipped with turbocharger to improve the truck power and Engine efficiency
