Vertical Type Glass Sand Blasting Machine in China in Guangdong, China
New
Doubleclick to zoom in
Contact the seller for
additional photos and information.
Specifications
- Condition
- new
- Certification
- CE
- Glass thickness
- 3-40mm
- Shipping cost
- Contact the supplier about freight and estimated delivery time.
- Secure payments
- Every payment you make on is protected by the platform.
- Refund policy
- Claim a refund if your order doesn't ship, is missing, or arrives with product issues.
- Voltage
- 220/240/380/415/480V
- Control system
- Semi-Automatic
- 1.description
- Sand Blasting Machine
- 2.model
- Yd-Sb-2000
- 3.color
- Creamy-White/Optional
- 4.glass height(mm)
- 2000
- 5.brand name
- Yd
- 6.place of origin
- Guangdong China(Mainland)
- 7.glass transfer speed(m/min)
- 5
- 8.nozzle moving speed(m/min)
- 5~25
- 9.power(kw)
- 4.5kw
- 10.weight(kg)
- 1500
- Structure
- Vertical
- Transport package
- Bubble Plastic Bag
- Specification
- CE
- Hs code
- 84642010
- Production capacity
- 20 Sets Per Month
- Subcategory
- Glass machine
- Subcategory 2
- Glass sandblasting machine
- Subcategory 3
- Manufacturing & processing machinery
- Listing ID
- 84023449
Description
Product Description
Vertical type glass sand blasting machine in China
Specifications:
1. Easy operate
2. Sand blasting patterns
3. Or trademark on glass surface
4. Or sand blast the whole surface for separate wall
Glass types of sand blasting machine:
A. We have three types of sand blasting machine
B. Sand blast the whole surface for separate wall and shower room door.
Main Technical Specification:
Model Number
YD-SB-1500
YD-SB-2000
YD-SB-2500
Glass height(mm)
1500
2000
2500
Max.glass size(mm)
1500×3000
2000×3000
2500×3000
Min.processing size(mm)
200×500
200×500
200×500
Glass transfer speed(m/min)
5
5
5
Nozzle moving speed(m/min)
5-25
5-25
5-25
Suitable working pressure, continues
0.6MPa-0.8MPa
0.6MPa-0.8MPa
0.6MPa-0.8MPa
Suitable air pressure power
2.4m ²/min 15kw
2.4m ²/min 15kw
2.4m ²/min 15kw
Power(kw)
3.
