1978 MITCHELL 2 DIE HYDRA PUSH in North Branford, CT, USA
Used
Doubleclick to zoom in
Contact the seller for
additional photos and information.
Specifications
- Condition
- used
- Year
- 1978
- Stock number
- 13114
- Capacity
- Rated - 33,000 Lbs. (14969 KG) @ 1989 PSI
- Die #2
- Up to 4 Nibble Strokes
- Pointing speeds
- Advance - 212 IPM @ 2000 PSI
- Point length
- Automatic By (3) Position Selector Switch
- Maximum travel of dies
- 12" (304mm)
- Length of gripper jaws
- 13" (330mm)
- Die index mechanism
- Hydraulic Cylinder
- Clamping mechanism
- Hydraulic Cylinder & Double Toggle
- Traverse mechanism
- Hydraulic Motor
- Tube gripper jaws
- Octagonal - Quick Rotate Type (8 Sided)
- Current grip sizes
- .625" (15.8mm), .687"(17.4mm), .750" (19mm), .812"
- Equipped with
- Push-Button & Controls; Vickers Pumps & Valves.
- Motor data
- Hydraulic - 20 HP Reliance, 230/460/60/3-1160 RPM
- O.a. dimensions
- 6' (1.82m) W x 11'4" (3.45m) L x 6'2" (1.879m) High
- Weight
- 6,900 Lbs. (3129.8 KG) Approx.
- Note
- Machines appears to be nearly unused since 1998 rebuild.
- Included
- Photos, Complete Manuals, Prints, and Schematics
- Category
- Bending & Forming in USA
- Subcategory
- Swagers
- Subcategory 2
- Equipment
- Listing ID
- 81528373
Description
1 1/16" (27mm) MITCHELL HYDRA-PUSH 2-DIE HYD. COILED ROD PUSH POINTER (13114)
MACHINE# 13114
Originally built for Nelson Steel & Wire. It was used to point coiled rod
coming off of a horizontal payoff going to a vertical bullblock. Pointer
slides into alignment between payoff and drawer to point the coil then
slides back out of the way.
Specifications:Manufacturer: George Mitchell & Co. (U.S.A.)
Maximum - 41,480 Lbs. (18815 KG) @ 2500 PSI
Automatic Cycle: (1) or (2) Die Reduction in Point Mode or Nibble Mode:Die #1: Up to 4 Nibble Strokes
Return - 271 IPM @ 1000 PSI
Die Holder: 2-Hole Rotary with 4.010" (101.8mm) O.D. w/3" (76mm) I.D. Round x
2-9/32" (57.9") Deep Cavities, w/1-1/2" (38mm) Dia. Relief Hole Behind Die
(20.6mm), .875" (22mm), .937" (23.7mm), 1" (25mm), 1.062" (26.9mm)
Current Est. Pointing Dies for Taking 1-1/16" (26.9mm) Down to 7/8" (22mm)
in Two (2) Hits
Coolant - 1/2 HP Reliance, 230/460/60/3-1140 RPM
**PRICE QUOTED AS IS WHERE IS SUBJECT TO PRIOR SALE**
