TDK 1300 in Szekszárd, Hungary
New
Doubleclick to zoom in
Contact the seller for
additional photos and information.
Specifications
- Condition
- new
- Total weight (upper / lower*) technical weight
- 13000 kg
- Dead weight (depending on equipment)
- 3000 kg
- Cargo weight
- 10000 kg
- Enclosure dimensions (l x w x h)
- 6180 x 2450 x 2240 mm
- Internal dimensions of the superstructure (h x w)
- 4510 x 2200/2300 mm
- Side wall height
- 600+600 mm
- Platform height (in case of standard tires)
- 1040 mm
- Volume
- 13.0 ~ 20.0 m3
- Gauge
- 1750 mm
- Square axis
- 80 mm
- Draw head max. load (upper / lower*)
- 2000 kg
- Max. speed
- 25 km/h
- Tire size
- 19.0/45-17
- Brake system - air brake
- two-wire
- Seed release hole
- 390 x 290 mm
- Stages of hydraulic cylinder
- 5
- (diameter)
- (60/75/90/105/120
- Cylinder height
- 1875 mm
- Tilt angle to the side/back
- 45° / 50°
- Required amount of oil
- 14,0 l
- Required traction demand kw / le
- > 59 kW / 78 HP
- Kicked chassis
- parabolic
- Sidewall relief springs
- Standard equipment
- Central opening
- Standard equipment
- Triangular front and rear riser
- Available options
- Gumming
- 355/60 R18
- 40 km/h version / two-wire air brake
- Available options
- Bottom coupling - tow eye /
- Available options
- Hydraulic support leg / y-version
- Available options
- Rear hitch
- Available options
- Removable protective cover on the back
- Available options
- Hardox® platform plate
- 4 mm
- Superstructure dimensions
- 4510 x 2406mm
- Side height (instead of series)
- 500+500mm / 600mm / 800+600mm
- Third riser
- 500 / 600 mm
- Silo side walls - hydraulic door
- Available options
- Extension / pipe extension is the core ejector
- Available options
- Category
- Dump Trailers in Hungary
- Subcategory
- Tandem axle tractor-drawn trailers
- Listing ID
- 74567224
Description
Bottom and top sides made of stable C-profile 4 mm and 5 mm platform plate Tilting to three sides (to the side and back) Chrome-plated telescopic working cylinder with safety limiter Multiple opening options for the sides High (standard - springs above the axle) and low version (the springs under the chassis ensure optimal use and prevent tire wear) Central opening of the sides Side wall relief springs Detachable rear pillars Widening platform from 8 t load weight, equipment for strengthening the sides Side tensioning chain Core release opening Stable step in front Wheel support wedges Second trailer towing option 12 V electrical system Handbrake Lower or upper gear Adjustable support wheel or support leg Drawbar Several types of brake systems are available: running brake, hydraulic brake or air brake system
