Cost-Effective Interleave Non Rip Drawstring Draw Tape Bag Machine Garbage Bag on Roll Trash Bag Machine Coreless Bag Making Machine Intermediate Speed in Jiangsu, China
New
Doubleclick to zoom in
Contact the seller for
additional photos and information.
Specifications
- Condition
- new
- After-sales service
- 1
- Shipping cost
- Contact the supplier about freight and estimated delivery time.
- Secure payments
- Every payment you make on is protected by the platform.
- Refund policy
- Claim a refund if your order doesn't ship, is missing, or arrives with product issues.
- Product line
- 1
- Lines
- 1
- Voltage
- 220/380V
- Seals mode
- Side Seal
- Speed
- Medium
- Continuous-rolled
- Yes
- Sealing & cutting
- Non Rip
- Layer
- Single
- Machine type
- Bag Forming Machine
- Computerized
- Computerized
- Servo motor
- 4sets
- Servo motor brand
- Made in Taiwan
- Machine inverter brand
- Made in China
- Temperature controller
- Made in Taiwan
- After-sale service provided
- Engineers Available to Service Machinery Overseas
- Material
- HDPE,LDPE
- Machine control
- PLC ,Touch Screen
- Rewinder way
- Automatic Overlap Rewinder
- Machine brand
- Silstar
- Transport package
- Wrapping Film Packing or Packed in Wooden Case
- Specification
- CE, ISO9001: 2008, SGS, TUV
- Hs code
- 84778000
- Category
- Garbage trucks in China
- Subcategory
- Bag making machine
- Subcategory 2
- Packaging & printing
- Subcategory 3
- Plastic bag making machine
- Subcategory 4
- Machinery for packaging supplies
- Listing ID
- 103635869
Description
Product Description
1. Main control panel adopts touch screen Teco from Taiwan, high definition
2. The drive system of the whole machine adopts PLC Microcomputer control (Single Chip control system ) on the punch machine which integrates control of bag making part and punching part.
3. Set all functions with one touch screen, simple and easy operation.
4. Machine will automatically stop if film jammed which is detected by the sensor
5. Independent winder part, high efficient unwind control; max diameter of single unwinding is 800mm; unwinding roller is choked by air shaft,
6. Automatic fold function and put on conveyor unit by unit.
7. Automatic stacks the bag and collects.
8. When the bags stack at the Set numerical, mechanical hands will automatically grab bags and the machine will not stop.) on punch machine which integrates control of bag making part and punching part.
Product Parameters
Bag Width
700/800/900/1000 mm
Bag Length
800/900/1000 mm
Film thickness
