Automatic High Effective Ultrasound Bone Densitometer in Guangzhou, Guangdong, China
New
Doubleclick to zoom in
Contact the seller for
additional photos and information.
Specifications
- Condition
- new
- Model number
- MCI0715
- Note
- Printer is Optional
- 1. measurement parts
- radius and Tibia
- 2. measurement mode
- double emission and double receiving
- 3. measurement parameters
- Speed of sound (SOS)
- 4. analysis data
- T- Score, Z-Score, Age percent[%], Adull percent[%], BQI (Bone quality Index ), PAB[Year] (physiological age of bone), EOA[Year] (Expected Osteoporosis age), RRF(Relative Fracture Risk).
- 5. measurement accuracy
- ≤0.25%
- 6. measurement reproducibility
- ≤0.25%
- 7. measurement time
- <25 seconds
- 8. probe frequency
- 1.20MHz
- 9. date analysis
- it adopt a special intelligent real –time data analysis system, it selects the adult or child databases according to the age automatically .
- 10. temperature control
- Perspex sample with temperature instructions
- 12. probe crystal indication
- it display the working condition for the four crystal of the probe, and the signal strength for the ultrasonic reception.
- 13. daily calibration
- automatic calibrating after power on.
- 16. repot mode
- color
- 17. report format
- supply A4, 16K ,B5 and more size report
- 19. computer configuration
- CPU dual core, 4G memory, electronic hard disk, wireless mouse
- 20. printer
- optional
- 24. monitor
- 10.4’ color HD color LED monitor.
- 25. fluid protection
- main unit waterproof level IPX0, probe waterproof level IPX7
- Category
- Medical Imaging in China
- Subcategory
- Ultrasound machine
- Subcategory 2
- Portable ultrasound machine
- Listing ID
- 103512478
Description
Automatic High Effective Ultrasound Bone Densitometer
Configuration:
1. Ultrasound Bone Densitometer Main Unit
2. 1.20MHz Probe
3. Famous Brand Embedded Industrial Control Computer
4. Intelligent Analysis System
5. Calibrating Module (Perspex Sample)
6. Disinfectant Coupling Agent
Technical features:
1. Using the full dry technology, makes diagnostic more convenient.
2. The probe adopt the Technology of the United States DuPont, makes the probe to receive higher sensitivity and better reception.
3. the better ultrasonic frequency on the measuring position, with better penetrability, more effective signal
4. use the ultrasonic axial conduction technology, double emission and double receiving, it can provide more effective data
5. With innovative algorithm, effectively remove clutter and jamming signal, to get the valid data.
6. With a special correction system, to correct the system error effectively, get more accurate measurement results.
7.
