CNC Machine Lathe Precision Lathe Machine Vmc Jt-960V in Zhejiang, China
New
Doubleclick to zoom in
Contact the seller for
additional photos and information.
Specifications
- Condition
- new
- After-sales service
- 1 Year
- Application
- Metal
- Process usage
- Metal-Cutting CNC Machine Tools, CNC Non-Conventional Machine Tools, Metal-Forming CNC Machine Tools
- Movement method
- Point to Point Control
- Control method
- Closed-Loop Control
- Numerical control
- CNC/MNC
- Processing precision
- 0.01~0.02(mm)
- Performance classification
- High-End CNC Machine Tools
- Precision
- High Precision
- Net weight
- 6300kg
- Tool libranes
- 21 Arm Type Tool Libranes
- Standard system
- Mitsubishi M80
- Transport package
- Seaworthy Packing
- Specification
- 2700*2400*2750mm
- Hs code
- 8458110000
- Production capacity
- 1500sets/Year
- Category
- Lathes in China
- Subcategory
- Machine tools
- Subcategory 2
- Cnc machine tools
- Subcategory 3
- Manufacturing & processing machinery
- Listing ID
- 103108303
Description
Product Parameters
ITEM
UNIT
JT-960V
Workbench
Workbench size
mm
1060*580
Worktable load-bearing capacity
kg
800
T-slot width (width x spacing x number of slots)
mm
18*110*5
Trip
X-axis travel
mm
900
Y-axis travel
mm
600
Z-axis travel
mm
680
Distance from spindle end face to workbench
mm
110-790
Distance from spindle center to Z-axis rail surface
mm
610
Principal axis
Speed range
rpm
12000
Main spindle power (continuous/30 minute rated)
kw
7.5/11
Spindle torque(rated for continuous/15minutes)
Nm
35.8/70
Slope of spindle inner hole
BT40
Transmission mode
Direct-type
Feed
X-axis rapid displacement
m/min
30
Y-axis rapid displacement
m/min
30
Z-axis rapid displacement
m/min
30
Feed rate
mm/min
15000
