Fully Automatic Bolt Chamfering Machine with Auto Loader in Deyang, Sichuan, China
New
Doubleclick to zoom in
Contact the seller for
additional photos and information.
Specifications
- Condition
- new
- Place of origin
- Jiangsu China
- Application
- PIPE
- Key selling points
- High Productivity
- Function
- Out angle inside and surface of tube end
- Automatic grade
- Automatic
- Loader
- Automatic
- Processing length
- Customized
- Raw material
- Steel
- Controlling mode
- PLC
- Capacity
- OD3.2- 52
- Applicable industries
- Energy & Mining Construction works Building Material Shops Machinery Repair Manufacturing Plant
- Category
- Gear Finishing in China
- Subcategory
- Chamfering machine
- Subcategory 2
- Industrial machinery
- Subcategory 3
- Machine tool equipment
- Listing ID
- 103032264
Description
Product Application
to know more about us.
Working video of machine:
Fully Automatic Bolt Chamfering Machine with Auto Loader
DJ-52P-II double head chamfering machine is controlled by pneumatic, it can finish two ends of pipe / bar one time. Feeding / retracting and clamping by pneumatic, auto unloading. It has 2-step feed speed. The first step feed is high speed, then the second step feed speed is adjustable to produce clean and smooth cutting results. Changing sizes of cut are conveniently made by simply adjusting and changing cutterhead and clamp. With Taiwan core tech since 1989.
DJ-52P-II
P Pneumatic type
II Double head
Capacity Pipe Φ9 - 52 mm
Bar Φ6 - 38 mm
Pipe length 30 - 500 mm (standard) or customized
Cutterhead Φ20 - 52 mm (standard) or Φ9 - 18 (Option)
Motor 1.5 Kw, 4 pieces
Air Pressure 6-9 kg/cm2, 60 ml/min, 0.6-0.9 Mpa
$6,000 USD
