SMTCL Vertical CNC Lathe V6 Heavy Duty 3 Axis Vertical CNC Lathe Machine in Shanghai, China
New
Doubleclick to zoom in
Contact the seller for
additional photos and information.
Specifications
- Condition
- new
- Place of origin
- CHINA
- Certification
- CE ISO certification
- Cnc or not
- CNC
- Key word
- Vertical CNC Lathe
- Spindle nose type
- ; A2-8; A2-8; A2-11
- Output power of main motor
- KW; 15/18.5; 15/18.5; 22/30
- Maximum swing diameter over bed
- mm; Φ500; Φ650; Φ720
- Maximum cutting height
- mm; 350; 500; 650
- Minimum order quantity
- 1
- Packaging details
- The wooden case，Tin trunk ,Other seaworthy packing
- Payment terms
- T/T,L/C,,Western Union
- Supply ability
- 50 sets per month
- Item
- Unit; V2S; V4C; V4S
- Maximum cutting diameter
- mm; Φ330; Φ500; Φ600
- Spindle speed range
- r/min; 50-3000; 50-2500; 50-2500
- Maximum output torque of spindle
- Nm; 472 β motor 530 α motor; 549 β motor 715 α motor; 1160 β motor 1169 α motor
- Chuck diameter
- inch; 10‘’; 12‘’; 15‘’
- X-axis rapid traverse speed
- m/min; 30; 18; 18
- Z-axis rapid traverse speed
- r/min; 30; 18; 18
- X-axis travel
- mm; 200; 300; 300
- Z-axis travel
- mm; 400; 520; 690
- Tool post type
- ; Horizontal 8-position; Horizontal 8-position; Horizontal 8-position
- Tool size
- ; 25*25/Φ40; 25*25/Φ50; 25*25/Φ50
- Machining accuracy
- ; IT6; IT6-IT7; IT6-IT7
- Surace roughness of workpiece machined
- ; Ra1.25; Ra1.6; Ra1.6
- X-axis
- mm; 0.004; 0.005; 0.005
- Z-axis
- mm; 0.005; 0.005; 0.005
- Disks (including chuck and fixture}
- kg; 300; 350; 400
- Main unit
- kg; 4500; 6800; 7300
- L×w×h
- mm; 2000*1370*2275; 2260*1780*2880; 2260*1780*3060
- Category
- CNC Lathes in China
- Subcategory
- Vertical cnc lathes
- Listing ID
- 102865106
Description
SMTCL Vertical CNC Lathe V6 Heavy Duty 3 Axis Vertical CNC Lathe Machine
Vertical CNC Lathe Milling Combo
Heavy Duty Vertical CNC Lathe
Vertical CNC Lathe
Contact Us
Request A Quote
RELATED PRODUCTS
Contact Us
Product Description
Product Description:
SMTCL Vertical CNC Lathe V6 Heavy Duty 3 Axis Vertical CNC Lathe Machine
CNC vertical lathe is a machine tool for machining workpieces, which is characterized by a spindle perpendicular to the work surface. It uses a numerical control system to control the movement of the tool to achieve accurate machining operation. CNC vertical lathe is usually composed of machine tool body, workbench, spindle, tool holder, CNC system and so on. The machine body is usually composed of a bed, column and beam, providing stable support and rigidity. The workbench is a platform for holding workpieces and can be lifted and rotated as needed. The spindle is the shaft used to install the tool, and the speed and feed speed can be controlled by the CNC system.
