SUPERTECH CK6136 in Jiangsu, China
Used
Doubleclick to zoom in
Contact the seller for
additional photos and information.
Specifications
- Condition
- used
- Max. length of workpiece (mm)
- 750
- Structure
- Flat Bed Lathe
- Machining capacity
- Medium Duty
- Max. weight of workpiece(kg)
- 100
- Width of bed (mm)
- 330
- No. of spindles
- Single
- Number of axes
- 2
- Travel (x axis)(mm)
- 300
- Travel (z axis)(mm)
- 750
- Positioning accuracy (mm)
- ±0.001
- Repeatability (x/y/z) (mm)
- ±0.005
- Place of origin
- Jiangsu China
- Dimension(l*w*h)
- 210*130*145
- Voltage
- 380V
- Cnc control system
- GSK
- Tool post stations
- 4
- Weight (kg)
- 1650
- Key selling points
- Multifunctional
- Machinery test report
- Provided
- Video outgoing-inspection
- Provided
- Range of spindle speed(r.p.m)
- 30 - 3000
- Cutting torque
- 30
- Machine type
- Horizontal Metal Turning Lathe Machine
- Name
- High Economy Bench Lathe Machine
- Keyword
- Universal Metal Lathe
- Function
- Machining Metal
- Precision
- Precision
- Product type
- Bench Lathe Machine Tool
- Processing
- Metal Working Lathe Machine
- Application
- Material Processing
- Key word
- Heave Duty Lathe Machine
- Max. swing diameter (mm)
- 360
- Spindle motor power(kw)
- 7.5
- Category
- CNC Lathes in China
- Subcategory
- Lathe
- Subcategory 2
- Industrial machinery
- Subcategory 3
- Machine tool equipment
- Listing ID
- 102502115
Description
Product Description Of CK6136/750
The CK6136/750 CNC lathe offers a rich array of functions that make it highly versatile in machining operations. Firstly, its spindle system is capable of a wide speed range, allowing for efficient processing of different materials. Whether it's soft aluminum or tough alloy steel, the adjustable spindle speed from 30 to 3000 r/min (varying by model) can provide the optimal
cutting conditions. For instance, when machining aluminum, a relatively high spindle speed can be set to achieve a smooth finish and high productivity, while for alloy steel, a suitable lower speed can be selected to ensure sufficient cutting force.
Secondly, the X and Z axes movement is precise and flexible. With X-axis travel typically between 200 and 300 mm and Z-axis travel from 550 to 800 mm, it can handle a diverse range of part geometries. This enables the lathe to perform various operations like turning external diameters, boring internal holes, and cutting threads.
Find more
$7,714 USD
