CAMU – AEPI 10MT CNC SINGLE COLUMN VERTICAL TURNING & BORING MACHINE with Y-AXIS MOVABLE COLUMN (2) RAMS with Live Spindle & Table C Axis in Marietta, GA, USA
Used
Doubleclick to zoom in
Contact the seller for
additional photos and information.
Specifications
- Condition
- used
- Year
- 2014
- Stock number
- 11150
- Table diameter
- 3,400 mm
- Swing
- 10,000 mm
- Turning height
- 5,000 mm
- Table capacity
- 50 Ton
- Table turn speed
- 30 rpm
- Dimensions, machine only
- 12,800 x 5,800 x 8,000 mm
- Motor power
- 100 kW
- Machine weight
- 80 Ton
- Category
- Boring Mills in USA
- Subcategory
- With live spindle
- Subcategory 2
- Boring mills, vertical
- Listing ID
- 100694345
Description
- Fagor 80865 CNC Control
- Chip Conveyor
- Set of Boring Bar holders and 9 Turning Tool Holders
- FAGOR Electronic handwheel for axis movement in manual changeover and touches
- package of 5 motorizations (4 axes and an ISO 50 drilling spindle)
- SIEMENS vector 100KW AC motor variable speed for platform spindle with 4 ranges up to 30 rpm max
- High precision spindle center encoder for drilling
- (2) Two Automatic Tool Changer Carousels with 12 Positions
- Automatic door and air jet
- for turning RAM with hydraulic cylinder tool coupling system with standard AEPI attachment
- Milling and drilling spindle - tapping inside the second RAM carriage including the automatic ISO 50 tool attachment
- For interlocking in drilling and tapping with a maximum speed of 1500 rpm including precise positioning and locking of the spindle by means of an electro-hydraulic system with sliding jaws
- This position includes the application of the 18 KW drilling spindle motor and related power supply and control equipment and the external refrigeration system
- Operator protections and accident prevention equipment with 16 safety microswitches
