1999 OKUMA & HOWA VTM-65 in Warren, MI, USA
Used
Doubleclick to zoom in
Contact the seller for
additional photos and information.
Specifications
- Condition
- used
- Year
- 1999
- Stock number
- 25611
- Control
- FANUC 18T
- Dimensions
- 160.08" x 119.29" x 161.42"
- Weight
- 24,200#
- Equipped with
- Hydraulic System Automatic Tool Changer Chip Conveyor Pallet Changer (2) Pallets 50 Taper
- Table dia
- 29.5 in
- Swing
- 39.4 in
- Power
- 30.0 hp
- Rpm
- 1250.0 rpm
- Category
- CNC Lathes in USA
- Subcategory
- Boring mills, vertical, cnc, w/milling spindle & atc
- Listing ID
- 100479513
Description
VTM-65 3-axis vertical turning center combines the benefits of a vertical lathe with those of a machining center. The 50-taper 36-tool magazine enables this machine to offer both turning and milling operations on a single platform. It is the ideal machine for efficient low-volume parts production, including valve bodies and work that requires heavy milling. The box-way construction and wide, angular slideways on each axis provide high rigidity for accurate machining. A vertical axis counterbalance assures smooth, stable feed at all speeds. The headstock is fixed to the base, minimizing the influence of thermal changes and vibration on cutting accuracy. In addition, the VTM-65 is available with a wide range of standard accessories, including a spindle orientation function.
Specifications:
Maximum Swing Diameter: 29.53"
Maximum Machining Diameter: 25.59"
Maximum Machining Length: 25"
Maximum Workpiece Load: 1,760#
X-Axis: 19.69"
Z-Axis: 25"
C-Axis: 360 Degrees
Speed: 1,250 min.1
